Expansion joints and control joints are easy to ignore during a commercial repaint. They sit flush with the surrounding surface, they don't look like a problem, and most painters treat them like any other section of wall or floor. That's the mistake. When building movement causes a joint to flex, a rigid paint film across the gap cracks within weeks, and the failure spreads outward from there.
Apex Painting handles these joints on commercial surfaces across Melbourne regularly, and the approach differs depending on the joint type, the substrate, and whether the space is interior or exterior. Here's what the correct process looks like.
What expansion joints and control joints actually do
These two joint types are related but not identical. Expansion joints are designed to absorb movement between two separate structural sections, typically where different building masses meet or where thermal expansion is significant. Control joints are pre-formed breaks in a continuous surface, usually concrete or masonry, that encourage any cracking to happen at a predictable location rather than randomly across the slab or wall.
Both joints move. The degree of movement varies: a control joint in an interior concrete wall might flex less than a millimetre seasonally, while an expansion joint on an exposed facade can open and close by several millimetres across Melbourne's temperature range. Paint products that don't accommodate that movement will crack, and once the film breaks, moisture gets underneath and the adhesion failure accelerates.
Why standard paint systems fail across joints
Standard acrylic and enamel wall paints cure to a semi-rigid film. They'll handle minor surface movement, but they aren't formulated to bridge a gap that opens and closes repeatedly. The film fatigues at the joint edge and splits, often within a single season. On exterior surfaces exposed to direct sun, the thermal cycling is aggressive enough to crack even a freshly applied coat within the first summer.
The problem compounds on floors. If you're working on a commercial project where painted concrete floors cross an active control joint, a standard epoxy or polyurethane floor coating will bridge the joint, cure rigid, and delaminate in a strip either side of the line. The fix is to cut the coating at the joint edge before it cures, which creates a deliberate break rather than an uncontrolled crack. Most painters skip this step.
The correct product types for joint areas
For wall and ceiling surfaces, the right product near an active joint is a flexible elastomeric coating. These are acrylic-based systems with a higher elongation rating than standard paint, often 200% or more. They stretch with the substrate movement without tearing. Dulux, Taubmans and Haymes all manufacture elastomeric coatings suited to masonry and rendered walls. The application process is the same as standard paint, but the film builds thicker and the drying time is longer.
For floor joints, a polyurethane joint sealant is the correct solution for the joint itself. The sealant is applied into the joint cavity, tooled flush, and allowed to cure fully before any floor coating is applied. The floor coating is then cut in on either side, leaving the sealant exposed as a flexible working element. This keeps the painted field intact while the joint continues to move independently.
For exterior expansion joints on facades, the joint cavity should be prepared with a backer rod before sealant application. The backer rod (typically closed-cell polyethylene foam) controls the depth of the sealant and prevents three-sided adhesion, which would restrict the sealant's ability to move freely. Without the backer rod, the sealant bonds to the back of the joint as well as the sides, and the elongation capacity drops sharply.
Surface preparation at joint edges
Joint edges are often the most degraded sections of any commercial surface. Old sealant may be cracked, partially delaminated, or contaminated with paint overspray from previous jobs. Preparing the joint correctly takes more time than the surrounding wall, but it determines whether the new application holds.
Start by removing all existing sealant down to clean substrate. A utility knife, oscillating multi-tool or grinder with a segmented wheel are the practical options depending on access. Once the cavity is clear, wire-brush the joint faces to remove dust and loose particles, then wipe with a solvent to degrease. Any paint overspray on the joint face should be removed before new sealant is applied, since sealant won't bond reliably to a contaminated surface.
On masonry and concrete surfaces, check for efflorescence along the joint edges. White salt deposits indicate moisture movement through the substrate, and sealant applied over efflorescence will delaminate as the salts continue to migrate. Treat with a diluted acid wash, rinse thoroughly, and allow to dry fully before proceeding. This is the same principle that applies when addressing paint adhesion failures on commercial surfaces more broadly: the cause has to be resolved, not painted over.
Painting approach on either side of a joint
Once the joint sealant has cured, the adjacent painted surfaces need to be handled carefully. The transition from sealant to paint-ready substrate is rarely clean. The sealant surface itself is not paintable with standard systems: most sealants are silicone or polyurethane-based, and standard acrylics don't bond to either reliably without a primer designed for the purpose.
Where the design calls for a painted finish over a sealant-filled joint, use a specialist sealant primer before topcoating. These are typically solvent-based products applied in a thin film, left to tack, and then overcoated with an elastomeric topcoat within the open window the manufacturer specifies. Miss that window and the adhesion drops sharply.
Colour matching at the joint is worth discussing during the briefing stage. On large commercial facades with exposed expansion joints, the sealant will remain a slightly different surface texture to the surrounding render or masonry, and the topcoat may look marginally different across both. Setting accurate expectations with the client before the job starts prevents disputes afterwards. This is precisely the kind of detail that belongs in a thorough commercial painting brief.
Interior vs exterior joint treatment
Interior joints, particularly in climate-controlled commercial spaces, move less than exterior joints. The temperature differential is smaller, and there's no direct UV or moisture exposure. On interior walls with control joints, an elastomeric filler over the joint face combined with a flexible topcoat is often sufficient. The goal is to bridge the joint with a product that can absorb minor movement without cracking, rather than leaving the joint edge sharp and rigid under the paint film.
Exterior joints are a different category. UV exposure breaks down elastomeric films faster than interior products, and most manufacturers rate their exterior elastomeric coatings for 5 to 7 years over active joints before recoating is required. Factor that into the maintenance schedule for any commercial property with significant facade joint work. It's also worth considering seasonal timing: applying sealant or elastomeric coatings in Melbourne's summer heat, when substrate temperatures can exceed 50°C on a north-facing facade, shortens the cure window and risks solvent blistering. Autumn or spring are the practical choice for most exterior joint work.
How often joint areas need attention
A correctly prepared and sealed expansion joint in a commercial building should hold for 5 to 10 years under normal movement loads. The painted film over the joint will typically need refreshing before the sealant itself fails, particularly on south-facing exterior surfaces where moisture retention is higher. On floors, the sealant fill in control joints should be inspected annually in high-traffic areas: forklift traffic and pallet jack wheels put concentrated loads directly on joint edges, and the sealant can compress or tear under repeated impact.
Including joint inspection as a line item in any commercial maintenance plan keeps the cost of remediation low. Catching a joint where the sealant has begun to pull away from one face is a 30-minute fix. Waiting until moisture has tracked behind the surrounding floor coating turns it into a strip-and-relay job across a significant area.
Apex Painting assesses expansion joints and control joints as part of every commercial surface inspection. Getting the treatment right the first time is cheaper than repainting the same surface twice.
